DRAKA PRYSMIAN GROUP Cavo Ottico
CAVO 24FO OS2 DIEL.INT/EST.CCA GIALLO GIA 60102877
CAVO OTTICO LOOSE UNIVERSAL 24 FIBRE 50/125 OS2 PER INTERNO/ESTERNO ARMATURA DIELETTRICA 2000N GUAINA LSHF CCA-S1A-D1-A1 COLORE GIALLO
- Classe fibra OS2
- Numero Fibre 24
- Armatura Dielettrico
- Euroclass/Classificazione CPR CCA
a partire da: 6,98 € info
36943 opinioni Descrizione
Cavo Ottico DRAKA PRYSMIAN GROUP CAVO 24FO OS2 DIEL.INT/EST.CCA GIALLO GIA 60102877 E29-24-OS2GENERAL INFO
2000N, Ind/Out metal-free, Class Cca-s1a-d1-a1, gel-filled, water-blocked central tube cable with up to 24 fibres, glass yarn dielectric
armouring and FireRes® sheath. DIN/VDE: U-DQ(ZN)BH
CABLE FEATURES
Fibre optic cable with central loose tube filled with gel for structured cabling.
The cable is metal-free, longitudinally water blocked with a tensile strength of 2.0kN and certain degree of roden-proof protection.
The jacket is made of halogen-free, flame-retardant material according to IEC60332-1-2; IEC60332-3-24; IEC60754-2; IEC61034
for use in public buildings with a high personal risk according to Euro fire class Cca s1a d1 a1.
Use outdoors and in ducts, and as a flame-retardant cable indoors.
The fiber optic cable exceeds the requirements of EN 50173-1, ISO/IEC 11801, EN/IEC 60794-1 and EN/IEC 60794-6-10.
Scheda Tecnica
Generale
Tipo di cavo Loose monotubo
Tipo fibra Single mode
Classe fibra OS2
Utilizzo INT/EST
Nucleo/Rivestimento 9/125
Numero Fibre 24
Armatura Dielettrico
Materiale della guaina LSHF / LSZH / LS0H
Euroclass/Classificazione CPR Cca
Colore Giallo
